Class II A2 Biological Safety Cabinet

Class II A2 Biological Safety Cabinet

Class II A2 Biological Safety Cabinet

Class II A2 Biosafety Cabinet designed for routine lab use, delivering consistent airflow, high-efficiency filtration, and dependable protection for personnel and samples.

Tags: , , ,
Inquire Now

Description

Biological safety cabinet is necessary equipment in the laboratory in the search of microbiology, biomedical, DNA recombinant, animal experiment and biological products, especially in the occasion that operator need to adopt protective measure, such us medical and health, pharmacy, medical research. Our equipment provides a safety working environment which don’t have bacterial and dust in the process of bacterial culture.Three protection: operator, sample and environment. Airflow system: 70 % air recirculation, 30% air exhaust A2 Cabinet is suitable for working with microbiological research in the absence of working with microbiological research in the absence of volatile or toxic chemicals and radionuclide.
SpecificationBSC-1100IIA2-XBSC-1300IIA2-XBSC-1500IIA2-XBSC-1800IIA2-XBSC-2000IIA2-X
External Size (W×D×H)1100 × 750 × 2250 mm1300 × 750 × 2250 mm1500 × 750 × 2250 mm1800 × 775 × 2290 mm1950 × 800 × 2170 mm
Internal Size (W×D×H)940 × 600 × 660 mm1150 × 600 × 660 mm1350 × 600 × 660 mm1625 × 600 × 660 mm1800 × 600 × 660 mm
Tested OpeningSafety Height 200 mm (8″)Safety Height 200 mm (8″)Safety Height 200 mm (8″)Safety Height 200 mm (8″)Safety Height 200 mm (8″)
Max Opening420 mm (17″)420 mm (17″)500 mm (20″)550 mm (22″)400 mm (16″)
Inflow Velocity0.53 ± 0.025 m/s0.53 ± 0.025 m/s0.53 ± 0.025 m/s0.53 ± 0.025 m/s0.53 ± 0.025 m/s
Downflow Velocity0.33 ± 0.025 m/s0.33 ± 0.025 m/s0.33 ± 0.025 m/s0.33 ± 0.025 m/s0.33 ± 0.025 m/s
ULPA FilterTwo, 99.9995% efficiency at 0.12 μm, filter life indicatorTwo, 99.9995% efficiency at 0.12 μm, filter life indicatorTwo, 99.9995% efficiency at 0.12 μm, filter life indicatorTwo, 99.9995% efficiency at 0.12 μm, filter life indicatorTwo, 99.9995% efficiency at 0.12 μm, filter life indicator
Front WindowMotorized, two-layer laminated toughened glass ≥5mm, Anti UVMotorized, two-layer laminated toughened glass ≥5mm, Anti UVMotorized, two-layer laminated toughened glass ≥5mm, Anti UVMotorized, two-layer laminated toughened glass ≥5mm, Anti UVMotorized, two-layer laminated toughened glass ≥5mm, Anti UV
NoiseEN12469 ≤58 dB / NSF49 ≤61 dBEN12469 ≤58 dB / NSF49 ≤61 dBEN12469 ≤58 dB / NSF49 ≤61 dBEN12469 ≤58 dB / NSF49 ≤61 dBEN12469 ≤58 dB / NSF49 ≤61 dB
UV Lamp30W × 130W × 140W × 140W × 140W × 1
UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.
Illuminating LampLED lampLED lampLED lampLED lampLED lamp
12W × 212W × 216W × 216W × 216W × 2
Illumination≥1000 Lux≥1000 Lux≥1000 Lux≥1000 Lux≥1000 Lux
Consumption760W800W900W900W1500W
Waterproof SocketsTwo, total load of two sockets: 500WTwo, total load of two sockets: 500WTwo, total load of two sockets: 500WTwo, total load of two sockets: 500WTwo, total load of two sockets: 500W
STANDARD ACCESSORY
  • LED Lamp: 1pc
  • UV lamp: 2pcs
  • Remote control: 1pc
  • Waterproof sockets: 2pcs
  • Optional Accessory
  • Water and gas tap, base stand, universal caster with brake and leveling feet
ADVANTAGE
  1. Motorized front window.
  2. Time reserve function.
  3. ULPA filter life and UV life indicator.
  4. Automatic air speed adjustable with filter block.
  5. With memory function in case of power-failure.
  6. Audio and visual alarm (Abnormal airflow velocity; Filter replacement; Front window at unsafe height).
  7. Work area surrounded by negative pressure, it can ensure maximum safety in work area.
  8. Audio and visual alarm (Filter replacement, window over height, abnormal air flow velocity etc).
  9. Remote control: all functions can be realized with it, making the operation much easier and more convenient.
  10. Interlock function: UV lamp and front window; UV lamp and blower, LED lamp; blower and front window.
  11. Foot switch: adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm movement.
